Parameters

• I/O Interface

• Power

  DC 5V

• Ethernet

  5 * Gigabit RJ45 Ports

• Chip Solution

• Main Chip

  EN8850DN

• Performance

• Switching Capacity

  10Gbps

• Throughput

  7.44Mpps

• MAC Address

  2K

• Jumbo Frame

  15Kbytes

• Transfer Mode

  Store and forward

• MTBF

  100000 Hours

• Network

• Network Protocol

  IEEE802.3 (10Base-T)
  IEEE802.3u (100Base-TX)
  IEEE802.3ab (1000Base-TX)
  IEEE802.3x (Flow control)

• Network Medium

  10Base-T : Cat3,4,5 or above UTP(≤100m)
  100Base-TX : Cat5 or above UTP(≤100m)
  1000Base-TX : Cat5 or above UTP(≤100m)

• Certifications

• Safety certificate

  CE、FCC、RoHS

• Environmental

• Working Environment

  Working Temperature: -10~50°C
  Storage Temperature: -20~70°C
  Working Humidity : 10%~90%, non-condensing
  Storage Temperature: 5%~90%, non-condensing

• Indicator

• LED Indicators

  PWR(Power indicator)、 Link(Network Link)

• PWR

  On: power on
  Off: no power

• Link

  On: 10/100M link connection is normal
  Blinking: Data transmission is normal
  Off: link failure

• Mechanical

• Structure Size

  Product Size: 91*51*21.5mm
  Packing Size: 95*88*58mm
  Product Weight: 0.062Kg
  Packing Weight: 0.132Kg

• Packing Info

  Outer box size: 470*320*392mm
  Packing quantity: 100PCS
  Packing weight: 14.2KG

• Operating Voltage

  Power interface: DC2.1
  Switch input voltage: DC 5V1A

• Total power

  5W

• Packing List

  1. Switch:1 PCS
  2. User manual :1PCS
  3. Warranty :1 PCS
  4. Power Adapter:1 PCS
