Parameters

• Model number

  E242-48-G

• Port

  24*10/100/1000M RJ-45

• Switching Capacity

  48Gbps

• Forwarding Rate

  35.71Mpps

• Internal Cache

  4M

• MAC Address Table

  8K

• Jumbo Frames

  4Kbytes

• Forwarding Mode

  Store-and-Forward switching

• Standards

  IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x

  10Base-T: Cat3/Cat4/Cat5/Cat5e UTP/STP(≤100m)
  100Base-TX : Cat5/Cat5e UTP/STP(≤100m)
  1000Base-TX : Cat5/Cat5e UTP/STP(≤100m)

• Working Mode

  VLAN (Port Isolation): Ports 1 to 22 in isolation group cannot communicate with each other
  Default (Standard Mode): Support loop alarm
  Extend (Link Extension): Ports 1 to 22 support the work on 10/100/1000 Mbps speed based on their connection to the other end, and still reach up to 250 m transmission on 10Mbps

• Power Supply

  AC Input 100-240 V

• General

• Operating Temperature

  -10~50°C

• Storage Temperature and Humidity

  Storage Temperature: -40~70°C
  Storage Humidity: 5%~90%, non-condensing

• Operating Humidity

  10%~90%, non-condensing

• Dimensions (L*W*H)

  270*180*45(mm)

• Package Dimension (L*W*H)

  312*262*84(mm)

• Net Weight

  1.1kg

• Gross Weight

  1.6kg
