Product Comparison

Product

All

Difference

Parameter

Protocol
Model
Network Protocol
MTBF
VLAN
Multicast
Quality of Service (QoS)
Ethernet
Power Consumption
Power
Port
Environment
Operating Temperature
Operating Humidity
Standard
Storage Humidity
Storage Temperature and Humidity
Indicator
I/O Interface
Performance
Switching Capacity
MAC Address
Jumbo Frame
Transfer Mode
Network Medium
Safety certificate
Structure Size
Packet Buffer
Flash Memory
DDR SDRAM
VLANs
Industry Standard
L3 Function
IPv4
IPv6
L2 Function
Link Aggregation
Storm Control
Port Mirroring
Port Security
Spnning Tree Protocol
LLDP
Physical Specification
Power Voltage
Package List
Packet Forwarding Rate
Function Indication

PE244S-400-M-G

Product Line
- ZKBio Time API
- Biometrics Module SDK
- ZKBio CVSecurity API
- Biometrics Module
- Biometrics Scanner
- Biometrics Terminal
- Multi-purpose Integration
- Access Control
- Video Surveillance
- Smart Security Gate
- Smart Vehicle & Inspection
- Security Inspection
- Smart Home Security
- Video Intercom
- Body Temperature Detection
- Time Attendance
- Intelligent Commerce
- ZKBio Media
- Time Attendance
- Access Control
- ZKBio CVAccess
- ZKEasyGo
- ZKBio Time
- ZKBio Zlink
- ZKBio Media
- ZKBio WDMS
- ZKBio Time.Net
- ZKBio CVSecurity
- ZKBio Zexus Mobile APP
- ZKBio HA
- ZKBio Time Cloud
- ZKBio Partner
- ZKBio SIS
- ZKBio CVSecurity SmartLock
- ZKBio Zexus
- ZKBio Time Mobile APP
- ZSmart Mobile APP
- ZK SmartKey Mobile APP
- ZKBio Zlink Mobile APP
- AntarView Pro+
- ZKEasyGo
Product Line
Product Line

PE484S-400-M-G
PE244S-400-M-G
PE242-300-G
PE242-300-C
PE162S-300-M-G
PE162-200-C
PE082-120-G
PE082-120-C
E484-96-10G
PE042-55-C

Advisory Add to inquiry

PoE Protocol: IEEE802.3af (15.4 W), IEEE802.3at (30 W)
PE244S-400-M-G
IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1q, IEEE 802.1x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w
100,000 hours
Access/Trunk/Hybrid, VLAN Tunnel (Q-in-Q Tunnel), Congurable VID from 1 - 4094; Max.
256 static VLAN groups, Voice VLAN, MAC VLAN, Surveillance VLAN, Protocol VLAN, GVRP
IGMP Snooping, IGMP V1/V2/V3, Router Port, Static IGMP group address, IGMP groups
filtering, Querier, MLD Snooping, MVR
Traffic classification based, Strict priority and WRR, Port Priority, 802.1P Priority, IP TOS
Priority, IP DSCP Priority, Supports up to 8 queues per port, Priority Remarking
24*10/100/1000Mbps PoE Port
4*1000Mbps RJ45 Ports (Combo)
4*1000Mbps SFP Ports (Combo)
1*RJ45 Console Port
Product Power: ≤ 20W
POE Power: ≤ 380W
Input: AC 100-240V, 50-60Hz
Port Switch, Port Description, Port Speed, Port Duplex, Port Flow Control, Jumbo(Up to
10K), EEE, Fiber Module(DDM)
&
-10 to 50°C
10% to 90%, non-condensing
&
5% to 95%, non-condensing
-40 to 70°C
PWR(Power Supply), SYS(System), 1-24 PoE&ACT (PoE), 1-24 Link&ACT(Link&Act), 25-28
Link(Link), 25-28 Act (Act)
&
&
56Gbps
8K
9.6Kbytes
Store and Forward
10Base-T: Cat3, 4, 5 or above UTP(≤100m)
100Base-TX: Cat5 or above UTP(≤100m)
1000Base-TX: Cat5 or above UTP(≤100m)
Multi-mode Fiber: 50/125, 62.5/125, 100/140um
Single-mode Fiber: 8/125, 8.7/125, 9/125, 10/125um
CE, FCC, RoHS
Product Dimension: 440* 280*44mm
Package Dimension: 500*365*85mm
N.W: 3.65kg
G.W: 4.36kg
4Mbit
16MByte
128MByte
4096
EMI: FCC Part 15 CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD), EN61000-4-5 (Surge)
&
IPv4 VLAN Interface, IPv4 Static Routes, ARP
IPv6 VLAN Interface, IPv6 Static Routes, IPv6 ND
&
Supports load balance policy; Base on MAC and IP-MAC, Static and Dynamic Group,
Supports LACP, Up to 8 groups
Broadcast, Unknown Multicast, Unknown Unicast
One to one monitor, Many to one monitor, Ingress/Egress/Both, Up to 4 session groups
MAC Address Constraints, Port Security MAC Address, Protect/Restrict/Shutdown
STP/RSTP/MSTP, BPDU Filter, BPDU Guard, Edge Port
LLDP, LLDP MED
&
Input Voltage: AC 100-240 V
Power Supply: 52V7.69A
Switch 1 pcs, Power cord 1 pcs, User manual 1 pc, Warranty card 1 pc, Brackets 1 pair
(Selectable)
41.66Mpps
&
